Product description
1、Standardized products can be exchanged with standard products of other manufacturers；
2、Modular pluggable technology, which is free of tool for maintenance on site;
3、Achieve IP66 protection level to meet outdoor waterproof and dust-proof capability；
4、Patent packaging of imported high-efficiency chips which can save 60% energy than traditional spot lamps；
5、Professional light distribution design, uniform illumination without spot phenomenon；
6、LED is mercury-free, ultraviolet-free, radiation-free, and more conducive to environmental protection and the health of human eyes；
7、Various lamp housing shapes can be selected, free serialization, and full power solutions；
8、It can be connected by standard waterproof cable。
Product Dimension Map
Technical parameter
| Model | Power(W) | Driving current(mA) | Input voltage(V) | Color temperature(K) | Luminous flux(lm) | LED Light Source | Chromogenic index | Weight(g) |
| R2 | 50 | 1190 | 40.6-46.2V | 3000-6000K | 6250 | 3030/49 | 70/80 | 1030 |
| R2 | 60 | 1110 | 52.2-59.4V | 3000-6000K | 7500 | 3030/63 | 70/80 | 1040 |
| R2 | 70 | 1160 | 58-66V | 3000-6000K | 8750 | 3030/70 | 70/80 | 1050 |
Environmental parameters
| Project | Symbol | Parameter | Company | ||
| Typical value of pad temperature (self-cooling) | Ts | 80 (up to 50,000 hours of life B50L70) | ℃ | ||
| Working temperature | Topr | -30～50 | ℃ | ||
| Storage temperature | Tstg | -30～50 | ℃ | ||
| Environmental relative humidity | RH | 10-90 | % | ||
| Constant current | IF | 700 | mA | ||
Light distribution curve
